Whether one is making a RPG or a strategy game, there usually comes a time where designers want to attach a bunch of stats buffs and debuffs to each and every object in the game. The game actors start small but eventually we want our characters, units, countries and monsters stats to be able to be affected by a mix of equipment, perks, area effects, difficulty settings and whatnot. And if we don’t take care, it might turn our game into buff recalculation simulator 2000.

For those who never had design or implement a stats system, this might not sound like a very hard problem at first glance. After all, shouldn’t it simply be a simple struct with a bunch of values in it? It could, but it depends a lot on what your system can and cannot handle.

Say that we want our actors to have a bunch of stats that can be affected by various sources as we mentioned in our intro paragraph. Let’s ask a few questions about the extents of our system.

To cache or not to cache?

First let’s get the most basic question out of the way: “do we need store the sum total of a given stat with all buffs applied?”. After all, we could simply recalculate it on the fly each time. This helps us framing the problem domain as fundamentally a caching issue. It’s often said that cache invalidation is one of the two hard problems in software engineering, so can we dispense with it?

This might sound like a no-brainer but it actually depends a lot on the game, and then possibly on the stat itself. It forces us to ask ourselves (and the designers): how often does this value change compared to how often it is used. This is made trickier by the fact that the answer might change as the game design evolves. Maybe the designer has great plans for a given stat, but it turns out “bonus torpedo speed for submarines in deep waters” isn’t a value that is often used in the game¹, or maybe a stat started as a niche thing, but became ubiquitous over the years.

On a similar note, how expensive is the value itself to compute? Is it just about querying a couple values and summing them? Does it need to iterate over collection of objects from possibly dozens or thousands of potential contributors? And finally, does it need to recursively query values from another game object that will likely be using the same system?

Assuming we see a need for caching at least some class of stats, let’s continue with our next question.

Source tracking

Another very important question is “do we need to keep track of the contributors to a given stat?”. In the most basic case it’s not necessary. We could simply have a value, add to it when a buff is activated and subtract from it when they’re disabled (for example when a character equips or unequips a piece of equipment).

I say very important because it can easily be overlooked in the early stages of development. At first glance it looks like it won’t be necessary. The architecture gives us clear OnEnable() and OnDisable() callbacks that we can use to make sure the value is up to date. The designers don’t foresee the need to track where a buff comes from. They even thought about stacking rules and concluded that it’s fine to stack multiple sources so we won’t need to make sure only the highest spell effect should apply if multiple are present.

But then the first beta test feedback comes back, and the most common comment is that the UI doesn’t show the breakdowns and it’s impossible to understand why a given stat sums up to a given value. Or maybe QA complains that it’s hard to test whether or not the buff system actually works and requests at least a debug tooltip explaining how the value was calculated.

So… does it mean we should always keep track of breakdowns in our stats caching system because we’ll always need to at least display it in some form? From my experience, I’d argue mostly yes, although I’ve considered cheating once or twice. Given how expensive the whole system can end up being², one could consider having the UI breakdown code path bypass the caching system and redo the calculation on the fly, since we usually only display a handful breakdowns per frame. The displayed value can end up slightly out-of-sync with the cached value that is actually used by the tick updates, which can confuse players and testers alike. If you can afford it, not tracking buffs sources in the cache will save precious CPU cycles (and memory).

The one thing I definitely don’t recommend is forcing a cache recalculation on the fly (with breakdowns) when the UI needs it. I have fixed several out-of-sync MP bugs in my career because of it. And even for single-player only games, this introduces the ability for the UI to write to the gamestate on the fly, which if you’ve followed my previous articles should know that I’m very much against.

Pilot

With that out of the way, let’s talk about how this article got started. I recently had the opportunity to consult for Galactic Starfish on their upcoming title Strategeist. One of things I noted is that, much like every Grand Stategy Game I know of, there was a performance issue with their modifier system.

They kindly allowed me to use their source code as a “real-world” benchmark to test out various implementations for the purpose of this article³. I wouldn’t take the current numbers as any indication of how the final release might eventually look like, they are only given to illustrate the impact of various implementation choices.

So, let’s start with our baseline implementation:

using StatID = uint32_t;
using BuffSource = uint64_t;

struct Stats
{
    struct Entry
    {
        double value;
        std::unordered_map<BuffSource, double> sources;
    };

    std::unordered_map<StatID, Entry> entries;
};

Pretty straightforward so far. In the case of Strategeist there is at the moment 480 unique stats in the game. Grand Strategy games usually get into the thousands. Those should probably be split up in categories (by which final game object classes they can apply to), but still that’s probably a good representative number.

Now as I mentioned before, this implementation was fairly expensive to run. On my i7-10700, I measured the cache recalculation of each in-game country (the actor the player controls) to around 163.7us per run. Of course this is done for each country in the game, and if you’re familiar with map games you already know that there are hundreds of them in the game.

While there are probably things that can be improved in the calculation themselves, for the rest of this article I want to focus on how much could be achieved by just changing the underlying storage.

So you’re like a good demon? Bringing allocations?

While I first used Unreal Insights as an instrumentation profiler to see the modifier update stand out in the tick profile, switching to a sampling profiling (even one as basic as the one embedded in Visual Studio) was enough to confirm my suspicions: using those containers sparked a lot of allocations to the point that most of the update was spent in new and delete. Unreal’s TMalloc is better than the default malloc provided by Windows’ CRT, but it was still a major issue.

As far as associative containers go, std::unordered_map isn’t great. It’s better on MSVC than on Clang/GCC due to the way it avoids modulo but it’s still not great. Especially because the issue here isn’t lookup time, it’s insertions/removals that trigger a bunch of new and delete. This is due to the fact that std::unordered_map is basically implemented as std::vector of std::list, with each entry being it’s own heap allocated std::pair.

Looking at usage patterns by going through the code I noticed that we barely make use of inner std::unordered_map in a way that matters. The need for O(1) lookup of a given BuffSource in a given entry is rare, mostly limited to UI. Most entries will only have a handful sources, with the maximum case being maybe a dozen or two.

As it turns out, modern CPUs are actually quite good at brute-force linear search through small arrays. We could turn the inner std::unordered_map into a std::vector and use std::find_if to find the right pair. If we really needed it, we could even make it two vectors (one for keys, one for values), which could turn our std::find for a given key into a handful of SIMD uint64_t compares.

Making our sources into a std::vector<std::pair<BuffSource, double>> already yields quite impressive results: 91.8us. It also lowers the memory footprint (vector is more memory efficient than unordered_map for the same size/capacity).

Trying out Unreal types

Since we’re using Unreal Engine 5, we might as well try out their own vector alternative. After all there’s always people in my comments telling me that the STL is bad and every gamedev™️ should rewrite it even on a solo project. I know I’m being cheeky but this is a recurring thing I’ve been dealing with for years. In my book the bare minimum Unreal should do to win me over would be to work as a drop-in replacement of std::vector (like EASTL does), but sadly it doesn’t. Iterators are not copyable for some reason (which makes it unusable with most of <algorithm>), and none of the methods names match the STL besides begin() and end() (if they exist at all).

Either way, let’s bite the bullet and try replacing our origins once more with TArray<std::pair<BuffSource, double>>.

The result gives us 86.6us on average. That is 5us better. This is not bad, but I’m not sure it’s worth the hassle especially when the main performance improvement can be gained without it.

See, the main reason why this is faster is that Unreal’s TArray allocates at least 4 elements when it grows from 0 capacity (unless you set a flag asking it to be as conservative as the STL). This avoids the common pitfall with std::vector that it reallocates when going from capacity 0 to 1, then 1 to 2, then 2 to 3, and (if unlucky) from 3 to 4 due to the way the geometric growth factor math works. I agree with Unreal devs that for most cases this is probably a better strategy. In particular, I would love if the STL had a basic heuristic to avoid the 0 -> 1 -> 2 -> 3 -> 4 reallocs under a certain element size. Worst case scenario, it can be added on our side with a simple if (v.capacity() == 0) v.reserve(4); check.

Either way, there’s something even better than 1 allocation for small size. That’s no allocation. This is usually called a small vector (because it does Small Buffer Optimization, like std::string). They aren’t in the STL (sadly) but can be found in common libraries like Abseil and Boost. Or since we’re using Unreal, we can use their TInlineAllocator with our TArray:

using Sources = TArray<std::pair<BuffSource, double>, TInlineAllocator<4>> sources

This brings us down to 69us per update by avoiding allocations entirely for origins for most entries, unless they have a lot of buffs associated with them, in which case the geometric allocation formula kicks in, making sure we only (re)allocate 1 or 2 times as we grow the array. We’re already twice as fast as our baseline!

Arrays, arrays everywhere!

Now you may be thinking: “well if the inner container is faster as an array, shouldn’t we also do it for the outer container?”. Congrats, I thought the same. Because that what’s been done on games like Europa Universalis IV and Hearts of Iron IV. Except there’s a catch.

static constexpr std::size_t MaxStats = 480;
std::array<Entry, MaxStats> entries;

… and our average stats recalculation becomes 1142.8us. One entire millisecond per actor. With several hundred actors we’re looking at a tick that may take up to a whole second. It’s a disaster! What’s gone wrong?

The issue is that the calculations make use of temporary Stats variables before adding them to the main country stats. Each time they allocate about a hundred kilobytes. Even if they carry only a few values with one source each. While this probably indicates an over-reliance on temporary variables that could use a re-architecture, it does illustrate a point. Maybe not all stats need to use a large (but mostly empty) storage. Some systems and game objects with few actual entries would probably still benefit from the sparse storage offered by unordered_map.

So what if we left the storage strategy up to the user? After all, they probably know better which is best in a given corner of the codebase.

using ArrayEntries = std::vector<Entry> entries;
using MapEntries = std::unordered_map<StatID, Entry>;
std::variant<MapEntries, ArrayEntries> entries;

That way, the default behaviour is to use the sparse map storage that is optimized for objects that only carry a few active stats, while bigger objects (like countries) can switch to the array version. Note that we switched from array<Stats, 480> to vector<Stats> to ensure the size of an empty Stats object remains minimal. We will allocate once for objects we switch to the vector variant, a perfectly acceptable cost that is paid only once upon init/construction.

The results actually show a huge jump in performance: 45.1us. We’re now almost 4 times faster. Not only are lookups/inserts much faster, but also since we now have a vector as base we can make sure we don’t free any memory upon clear. The origins array under each Entry will never need to allocate for most countries after one tick, because we will keep the capacity untouched. This is one of the big advantages of dense arrays as they can easily preserve inner container allocations (it’s not impossible to do with maps but you would need a custom allocator that reuses freed entries and keeps their origins array allocated).

Better maps?

We’ve been saying unordered_map isn’t very good, so what if we tried something else? Continuing the Unreal Engine theme, I considered using TMap but sadly I found the API really terrible, especially when trying to replace unordered_map for a quick test. Instead, I decided to use ska::bytell_hash_map, by the author of the previously linked C++Now talk on hash tables. If you’re curious about more options I found this article offers a good overview.

Since those are a drop-in replacement for std::unordered_map (mostly, remember inserts invalidate iterators 😉), it’s easy to try-out:

using MapEntries = ska::bytell_hash_map<StatID, Entry>;

This bring us our best timing of the whole experiment: 42.4us. The small scale of the improvement is mostly due to the fact that our country Stats container is using the array variant, so it only improves the temporary variables and friends used in the recalculation code.

If we switch off the array storage for countries and use the bytell_hash_map in all cases, we still get an honorable 53.43us. It also gives us a hint about the potential improvements we could get by improving our calculations’ usage of Stats outside of the ones stored inside the country.

Again all those numbers are given to illustrate the difference container choices can make without changing anything else in our stats/buff system. The relative ratio is probably a bit off because the baseline calculations could be improved⁴.

Final numbers

During this little experiment I’ve tried many combinations. I’ll leave CPU and memory usage (size of Stats per country, including sub allocations) for reference:

• V1 (baseline) (unordered_map + unordered_map): 163.7us / 17918 bytes
• V2 (unordered_map + vector): 91.8us / 11629 bytes
• V3 (unordered_map + TArray): 86.6us / 18645 bytes
• V4 (unordered_map + TArray Inline): 69us / 18291B bytes
• V5 (vector + TArray Inline): 1142.8us / 994224 bytes
• V6 (variant<unordered_map,vector> + TArray Inline): 45.1us / 45096 bytes
• V7 (variant<bytell_hash_map,vector> + TArray Inline): 42.4us / 45096 bytes
• V8 (bytell_hash_map + TArray Inline): 53.4us / 25086 bytes
• V9 (bytell_hash_map + TArray): 71.4us / 19558 bytes
• V10 (variant<bytell_hash_map,vector> + TArray): 44.8us / 25314 bytes

By the way, I have not mentioned multithreading so far for a reason. While stats cache update is definitely something that can trivially be thrown at a parallel_for for each actor, I wanted to focus on single-core performance for the purpose of this article. Especially because, for those out there who are still using the default malloc() implementation from MSVC, you will feel the pain of trying to parallelize an operation that is mostly bound by allocations. As I mentioned in my talk last year, the default allocator uses mutexes which will make all your numbers explode. If your application doesn’t already have a custom general purpose memory allocator like Unreal does, consider switching to mimalloc⁵.

And with that being said, see you next time!

¹: This may or may not be inspired by a game I previously worked on

²: Both Stellaris and Victoria 3 were at some point or another bound by how fast they can recalculate stats/modifiers

³: In general it’s way too rare that game companies share any code outside of a few outliers. If you’re reading this and are in a position to change this, please encourage your company to open-source past titles for the purpose of education if anything.

⁴: I’ve improved performance on several live GSG titles over the years by removing temporary copies of Stats, believe me when I say it can make quite the difference.

⁵: Yes I know, mimalloc is made by Microsoft. Ironic, don’t you think?
